Scheme development of juice cup

Juice cup is a kind of machine that can quickly squeeze fruit and vegetable juice. It is small and can be used at home. It was invented by Dr. Norman Walker as early as 1930. On this basis, later, designers changed in and out of juice cups of different styles and principles. Function analysis: (also known as juice machine) make pure juice. After starting the machine, the motor drives the cutter net to rotate at high speed. Push the fruits and vegetables from the feeding port to the knife net, and the sharp thorn of the knife net cuts the fruits and vegetables. Under the action of the centrifugal force of the juicer generated by the high-speed operation of the knife net, the fruit residue flies out of the knife net into the slag box, and the fruit juice flows out of the knife net into the fruit juice cup.

Structure description of juicer cup PCB

1. The PCB structure diagram is fully compatible with the male mold shell in the market, and the PCB structure can also be customized according to customer requirements.

2. Use 18650 rechargeable battery for 1 month.

3. The main control MCU is sop14 encapsulated, with long standby time and low power consumption. It uses 18650 rechargeable battery and has a life of up to 1 month.
